DWanimal AIP-100 Veterinary Syringe Pump
DWanimal AIP-100 Veterinary Syringe Pump
Couldn't load pickup availability
Specification
- 4.3-inch color touch screen, clear visualizatio
- Simple rate mode with one-button start, easy to operate
- Compatible with syringes of various brands
- Multiple infusion modes to meet different clinical requirements
- User-friendly interface with audible and visual alarm system
- Rechargeable lithium battery can work continuously for about 5 hours
|
Model |
SP01 |
|
Compatible Syringes |
Various brands of sterile syringes: 5ml, 10ml, 20ml, 30ml, 50ml, 60ml |
|
Infusion Mode |
Rate mode, rate time mode, rate VIBI |
|
Flow Range |
5ml syringe: 0.1-150ml/h； 10ml syringe: 0.1-300ml/h； 20ml syringe: 0.1-600ml/h 30ml syringe: 0.1-900ml/h 50ml (60ml) syringe: 0.1-1500ml/h |
|
Volume |
0.1ml-9999ml |
|
Velocity Range |
0.1-100ml/h, adjustment 0.1ml/h 101-1500mlml/h, adjustment 1ml/h |
|
Time Preset |
1min - 99:59 min |
|
Accuracy |
±2% (the syringe should be properly calibrated) |
|
Alarm |
No syringe inserted, no operation, infusion completed, battery depleted, clogged, low power, parameters not confirmed, AC power failure, wrong syringe installation, etc. |
|
KVO Velocity |
2.5ml/h |
|
Power |
AC power: 100---240V, 50/60Hz; External DC power: 7.4 V |
|
Battery |
Built-in rechargeable lithium battery, 1800mAh |
|
Battery Working Time |
About 5 hours |
|
Screen |
4.3 inch LCD touch screen |
|
Size |
220mm*180mm*80mm |
|
Working Environment |
Temperature: +10~+30ºC Relative humidity: ≤70% Atmospheric pressure: 86 KPa~106KPa |
|
Storage Environment |
Temperature: -10~+55ºC Humidity: ≤80% |
